Comparison map
Electric Power: relationships and examples
Power is energy transfer rate. Choose an electrical power formula that matches the quantities and operating conditions supplied.Exam cue: At fixed current, P = I²R increases with R. At fixed voltage, P = V²/R decreases with R. State which quantity is held fixed.
- 1Electric Power -> General relation: P = VI for a steady direct-current component using its voltage and current.
- 2Electric Power -> Resistor relations: For a resistor, P = I²R = V²/R. These expressions follow by using V = IR.
- 3Electric Power -> Energy: Electrical energy E = Pt for constant power. Power in watts and time in seconds give joules.
- 4Electric Power -> Commercial unit: 1 kWh = 1000 W × 3600 s = 3.6 × 10⁶ J. A kilowatt-hour is an energy unit, not a power unit.
