Comparison map
Surface Area and Volume: relationships and examples
Unroll the curved surface and count the circular ends before selecting a cylinder area.Exam cue: The diagram models thin walls; use supplied internal or external dimensions as appropriate.
- 1Surface Area and Volume -> Curved surface: For r = 4 cm and h = 9 cm, the unrolled rectangle is 8π by 9 cm, with area 72π cm².
- 2Surface Area and Volume -> Circular ends: Each end disk has area 16π cm². A closed cylinder includes two; an open-top model includes only the base.
- 3Surface Area and Volume -> Surface totals: Closed area = 72π + 32π = 104π cm². Open-top area = 72π + 16π = 88π cm².
- 4Surface Area and Volume -> Capacity: Volume = base area × height = 16π × 9 = 144π cm³. Surface area and volume have different dimensional units.
