Comparison map
Quadrilaterals and Circles: relationships and examples
Properties depend on the type of figure, the circle’s centre and the labelled vertex order.Exam cue: Name the exact figure and the pair of angles used.
- 1Quadrilaterals and Circles -> Circle vocabulary: A radius joins centre to circle. A diameter is a chord through the centre and equals twice the radius.
- 2Quadrilaterals and Circles -> Cyclic angles: In cyclic ABCD, opposite interior angles A and C sum to 180°. The condition requires all four vertices on one circle.
- 3Quadrilaterals and Circles -> Solve the angle equation: If A = (2x + 10)° and C = (3x − 5)°, then 5x + 5 = 180. Thus x = 35, A = 80° and C = 100°.
- 4Quadrilaterals and Circles -> Different quadrilateral rule: A parallelogram has equal opposite angles. Do not transfer that equality to a general cyclic quadrilateral.
