Lines, Angles, and Triangles: relationships and examples
Use straight-line and triangle totals, and apply transversal rules only with a justified parallel-line condition.Exam cue: A diagram that looks parallel is not sufficient evidence that the lines are parallel.
- 1Lines, Angles, and Triangles -> At an intersection: Adjacent angles on a straight line total 180°. Vertically opposite angles are equal. Adjacent angles are not always equal.
- 2Lines, Angles, and Triangles -> Parallel lines: For parallel lines cut by a transversal, corresponding and alternate interior angles are equal. Co-interior angles total 180°.
- 3Lines, Angles, and Triangles -> Triangle total: Angles 50° and 60° leave a third angle of 70° because all three total 180°. Use the actual interior angles of the triangle.
- 4Lines, Angles, and Triangles -> Exterior angle: Extending a side at the 70° vertex gives an adjacent exterior angle 110°. It equals the two remote interior angles: 50° + 60°.
