Geometrical Construction: relationships and examples
Interpret compass arcs as distance constraints whose intersection fixes the required vertex.Exam cue: Each arc enforces a given distance; the finished shape alone does not show the construction method.
- 1Geometrical Construction -> Check feasibility: Side lengths 4 cm, 5 cm and 6 cm satisfy the triangle inequalities. The two shorter sides together exceed the longest.
- 2Geometrical Construction -> Fix a base: Draw a 6 cm base AB. This fixes the distance between two vertices while leaving the third vertex to be located.
- 3Geometrical Construction -> Intersect constraints: An arc centred at A with radius 4 cm and one centred at B with radius 5 cm meet at a point with both required distances.
- 4Geometrical Construction -> Retain evidence: Join the intersection to A and B and retain the arcs. A reflected intersection gives a congruent triangle unless a particular side of AB was specified.
