Pinhole Camera: concepts and evidence
A pinhole camera forms an image on a screen inside a dark box. Straight light paths from different points of an illuminated object cross at the small opening.Exam cue: Brightness and sharpness are different. A larger opening can brighten the image while increasing overlap and blur.
- 1Pinhole Camera -> Image formation: Light from the top of the object reaches the lower part of the screen; light from the bottom reaches the upper part.
- 2Pinhole Camera -> Inverted image: The screen image is upside down because rays cross at the pinhole. The object itself has not turned over.
- 3Pinhole Camera -> Hole size: Within the simple ray model, widening a small hole admits more light but lets images from nearby points overlap, reducing sharpness.
- 4Pinhole Camera -> Safe observation: Use an ordinary illuminated object for classroom checks. Never look directly at the Sun or through a pinhole pointed at it; solar projection is viewed on a screen.
